AgTec Non-Woven 4.5oz Drainage and Separation Geotextile (3ft x 100ft)
This 4.5oz non-woven polypropylene filter and drainage fabric is ideal for soil filtration and erosion control. It allows water to pass through, while holding soil and aggregate in place. Resistant to rot, chemicals, and UV degradation.
AgTec Non-Woven 4.5oz Drainage and Separation Geotextile (3ft x 100ft)
Features:
- Formed from a non-woven network of polypropylene fibers
- Holds soil aggregate in place while allowing water to drain
- Ideal for French drains, trench drains and blanket drains
- Ideal for erosion control
- Durable
- Resistant to UV degradation
- Resistant to rot and biological degradation
- Resistant to chemicals
- High tensile strength
- Flow rate: 120 gpm/ft2
This non-woven polypropylene filter fabric is used for soil separation and drainage. Use for subsurface drainage and filtration applications to prevent clogging and to improve performance of your drain systems. Extends the life and usefulness of French drains, trench drains and blanket drains. This fabric offers excellent filtration to help prevent dirt and aggregate from clogging your drains.
This filter fabric provides excellent soil retention and and reinforcement. It can also help control weeds, though it is not ideal for above ground or high traffic areas. Can be used in a wide variety of applications including subsurface drainage and path/roadway separation applications.
Applications include drains, walkways, patios, water features, under riprap to divert excess water, erosion control, retaining walls and heavy duty drainage.
Ship weight: 9.5 lbs
Specifications:
|
|
TEST METHOD |
MARV ENGLISH |
MARV METRIC |
|
Tensile Strength (Grab) |
ASTM D4632 |
120 x 120 lbs |
534 x 534 N |
|
Elongation (Grab) |
ASTM D4632 |
50% x 50% |
50% x 50% |
|
Trapezoidal Tear Strength |
ASTM D4533 |
50 x 50 lbs |
222 x 222 N |
|
CBR Puncture |
ASTM D6241 |
335 lbs |
1,490 |
|
UV Resistance (500 hrs) |
ASTM D4355 |
70% |
70% |
|
Apparent Opening Size* |
ASTM D4751 |
70 US Std. Sieve |
0.212 mm |
|
Permittivity |
ASTM D4491 |
1.7 sec-1 |
1.7 sec-1 |
|
Water Flow Rate |
ASTM D4491 |
120 gpm/ft2 |
4,889 lpm/m2 |
| Cloth Length | 100 Feet |
|---|
